Insize Digital Height Gage With Driving Wheel-1156 Series
-
DIGITAL HEIGHT GAGES WITH DRIVING WHEEL
Non waterproof
Resolution: 0.01mm/0.0005"
Buttons: on/off, zero, mm/inch, preset +, preset -, ABS/INC
Automatic power off, move the digital unit to turn on power
Carbide tipped scriber
Made of stainless steel
Battery CR2032
Data output
Supplied with dust cover
With dial test indicator holder
Optional accessory: data output cable (code 7315-22, 7302-22), clamp for protractors (code 2372-CLAMP)
1156-300 and 1156-1000
Scriber (included)
Dial test indicator holder (included)
Clamp for protractors (optional)Code Range Accuracy Length (L) Width (W) Height (H) a b c h 1156-300 0-300mm/0-12" ±0.03mm 515mm 180mm 55mm 80mm 30mm 35mm 9mm 1156-600 0-600mm/0-24" ±0.05mm 815mm 180mm 55mm 80mm 30mm 35mm 9mm 1156-1000 0-1000mm/0-40" ±0.07mm 1220mm 265mm 70mm 92mm 48mm 40mm 12mm
Original: $239.79
-65%$239.79
$83.93
Description
-
DIGITAL HEIGHT GAGES WITH DRIVING WHEEL
Non waterproof
Resolution: 0.01mm/0.0005"
Buttons: on/off, zero, mm/inch, preset +, preset -, ABS/INC
Automatic power off, move the digital unit to turn on power
Carbide tipped scriber
Made of stainless steel
Battery CR2032
Data output
Supplied with dust cover
With dial test indicator holder
Optional accessory: data output cable (code 7315-22, 7302-22), clamp for protractors (code 2372-CLAMP)
1156-300 and 1156-1000
Scriber (included)
Dial test indicator holder (included)
Clamp for protractors (optional)Code Range Accuracy Length (L) Width (W) Height (H) a b c h 1156-300 0-300mm/0-12" ±0.03mm 515mm 180mm 55mm 80mm 30mm 35mm 9mm 1156-600 0-600mm/0-24" ±0.05mm 815mm 180mm 55mm 80mm 30mm 35mm 9mm 1156-1000 0-1000mm/0-40" ±0.07mm 1220mm 265mm 70mm 92mm 48mm 40mm 12mm
